AR005_Frequency band (ric.):

UHF

AR010_Frequency range (ric.):

785.500 ~ 788.750

AR015_Preset channel (ric.):

16

AR020_Compatible Channel:

4

AR025_Suitable systems:

4

AR030_Modulation (ric.):

PLL

AR035_Deviation (nom/peak) (ric.):

25kHz/48kHz

AR040_Frequency Stability (ric.):

+-15 ppm

AR045_AF frequency response (ric.):

60Hz -18 kHz

AR050_Signal to Noise ratio (ric.):

110 dB(A)

AR055_T.H.D (ric.):

1% @ 1 KHz

AR060_Deviation peak sensitivity (ric.):

3µV (52dB S-N)

AR065_Output voltage (ric.):

balanced output +10dB, not balanced output +4dB

AR070_Output (ric.):

XLR, Jack

AR080_F/N ratio (ric.):

80 dB

AR085_P/N ratio (ric.):

80 dB

AR180_Rack Unit (19'):

1/2

AR150_Type (mic.):

Dynamic

AR155_Polar pattern (mic.):

Cardioid

AR140_Microphone type:

hand

AR003_Receiver principle:

True Diversity

AR090_Power supply (ric.):

external power supply 12V

AR095_RF squelch (ric.):

+50 dB

AR100_Squelch control (ric.):

yes

AR105_Operating temperature (ric.):

-10°C ~ +55°C

AR115_Output power 50 ohm (trasm.):

8mW – 30mW

AR120_RF squelch (trasm.):

+50 dB

AR135_Input voltage (trasm.):

2 x 1,5V, AA type

AR160_Sensitivity (mic.):

1.5 mV/Pa

AR165_SPL (mic.):

150 dB

AR175_Features:

Big LCD Display, battery level, also available the bodypack version with lavalier microphone. Plastic case.
