XT126WIFI
CONTROLLER DMX X-TREME XT126 WI-FI PEN
Description
2.4G Wreless DMX512 transceiver (RECEIVER/TRANSMITTER).
2.4G wireless DMX512 R/T.
RF frequency: 2.400-2.525G
126 channels jumping frequency automatically, high anti-jamming ability to ensure works reliability.
7 groups ID code settable, user can use 7 groups individual wireless net without any interfere.
Each other in the same place. (Tricolor LED displaying Indicators).
Input voltage: 5VDC 500mA MIN.
Communication distance: 300M (visible distance).
Work frequency section: 2.4G ISM, 126 channels frequency section.
Receiver sensitive: -106dBm.
Max transmitting power rate: 20dBm.
DMX signal port: 3 pin female plug.
Indoor use.
Working Temperature: -20°C~+45°C,10%~90%RH.
Product Details
STRXT126WIFI
- XT010_Wireless
- Yes
- XT015_Frequency
- 2.4G wireless DMX512 R/T
- XT020_CHANNELS
- 126 channels jumping frequency automatically, high anti-jamming ability to ensure works reliability.
- XT025_MAX DEVICES
- 7 groups ID code settable
- XT090_DMX In
- 3 pin female plug
- XT100_Max transmitting power rate
- 20dBm
- XT105_More info
- 126 channels jumping frequency automatically, high anti-jamming ability to ensure works reliability. Working Temperature: -20°C~+45°C,10%~90%RH.
- XT110_Input voltage
- 5VDC 500mA MIN
