XT240B

CONTROLLER DMX X-TREME XT240B

Description

• LED-backlit display
• Direct control of up to 16 channels (8 slider)
• Control up to 12 Fixtures of up to 16 Channels
• 30 banks, 8 programmable scenes
• 6 programmable chases of 240 scenes each
• Joystick for Control of scanners
• File dump allows data to be sent for received
between 2 units
• Controllable Chase and fade
• Midi control over banks, chases and blackout
• Manual override button allow you to grab any
fixture on the fly
• Blackout master button
• Auto mode program controlled by speed and fade
time sliders
• Fade time/assign fade time
• Reversible DMX channels fixture to react in
opposition to others in a chase
• Built in microphone for music triggering
• OUT: 3 pin DMX
• Midi in: 5 pin multiple socket
• USB socket for Gooseneck LED lamp (included)
• Audio IN: Jack (100 mV to 1Vpp)
• Power failure memory
• Fog machine connector
• Power requirements: DC 9-12V 300mA,
100V~240V, 50/60Hz
• Dimensions: 482x190x90 mm
• Weight: 3Kg

Street Audio
STRXT240B
XT005_Type
Controller DMX 16 canali
XT020_CHANNELS
16
XT025_MAX DEVICES
12
XT030_FADERS
8
XT045_Max scenes
240
XT060_BLACK OUT
Yes
XT090_DMX In
connettori XLR maschio/ femmina 3 pin
XT095_DMX Out
connettori XLR maschio/ femmina 3 pin
XT105_More info
Controllo mediante Joystick
XT110_Input voltage
DC 9-12V 300mA min
XT125_Dimensions
482x190x90 mm
